PR-UM-TnIR-A-10
Bruker BNS
Part No:PR-UM-TnIR-A-10-1PK
Variation
$590.00
Taxes and shipping costs are calculated at checkout
*Price and availability may vary by region due to local costs and regulations
75khz Tapping mode probes for AFM-IR
Quantity = 10 per pack
Key specification
| Nom | Min | Max | |
|---|---|---|---|
| Tip Radius (nm): | 20 | 35 | |
| Frequency (KHz): | 75 | 50 | 100 |
| Spring Constant (N/m): | 3 | 1.5 | 6 |
| Length (um): | 225 | 215 | 235 |
| Width (um): | 35 | 33 | 37 |
| Cantilever Thickness (um): | 2.8 | ||
| Cantilever Material: | Si | ||
| Reflex Coating: | Au | ||
| Geometry: | Rectangular |
Tip Specification
| Nom | Min | Max | |
|---|---|---|---|
| Tip Height (h): | 12.5 | ||
| Front Angle (FA): | 17.5 | ||
| Back Angle (BA): | 25 | ||
| Side Angle (SA): | 20 | ||
| Tip-side Coating: | Au |
