NPV-10
Description
NPV-10 Silicon Nitride probe for general contact mode imaging and force measurements in air and liquid. 4 triangular silicon nitride cantilevers provide spring constants from 0.06 to 0.35 N/m. •0.06 to 0.35 N/m, 20nm tip radius, gold reflex coating •Compatible with most commercial AFMs.
Quantity = 10 per pack
Technical Data
-
Key specification
Nom Min Max Tip Radius (nm): 20 70 Frequency (KHz): 65 40 90 Spring Constant (N/m): 0.35 0.175 0.7 Length (um): 120 115 125 Width (um): 25 20 30 Cantilever Thickness (um): 0.6 0.55 0.65 Cantilever Material: SiN Reflex Coating: Reflective Gold Geometry: Triangular Tip Specification
Nom Min Max Tip Height (h): 5.25 2.5 8 Front Angle (FA): 15 12.5 17.5 Back Angle (BA): 25 22.5 27.5 Side Angle (SA): 17.5 15 20
