VITA-MM-NANOTA-200
Description
NanoTA probes for MultiMode SPMs, 200 micron length. Note: Requires specialized probe holder model VITA-CH-MM. If using newer, High-Efficiency probe holder model VITA-CH-MM-HE, then probe modelVITA-HE-NANOTA-200 is required instead. Specifically designed for use with VITA module. Uses other than with VITA module void probe warranty.
Quantity = 5 per pack
Technical Data
-
Key specification
Nom Min Max Tip Radius (nm): <30 Frequency (KHz): 78 55 100 Spring Constant (N/m): 2.5 0.5 4.6 Length (um): 200 Cantilever Thickness (um): 2 Cantilever Material: Si Geometry: Rectangular Tip Specification
Nom Min Max Tip Height (h): 4.5 3 6
