SCANASYST-FLUID+
Bruker BNS
Part No:SCANASYST-FLUID+-1PK
Variation
$382.20
Taxes and shipping costs are calculated at checkout
*Price and availability may vary by region due to local costs and regulations
ScanAsyst Fluid+ probes, which marry the sharpness of a Silicon tip with the low spring constant and high sensitivity of a Silicon Nitride cantilever, for an unprecedented level of high resolution and force control on samples in fluid
Quantity = 10 per pack
Key specification
| Nom | Min | Max | |
|---|---|---|---|
| Tip Radius (nm): | 2 | 12 | |
| Frequency (KHz): | 150 | 100 | 200 |
| Spring Constant (N/m): | 0.7 | 0.35 | 1.4 |
| Length (um): | 70 | 65 | 75 |
| Width (um): | 10 | 5 | 15 |
| Cantilever Thickness (um): | 0.6 | 0.55 | 0.65 |
| Cantilever Material: | SiN | ||
| Reflex Coating: | Reflective Gold | ||
| Geometry: | Triangular |
Tip Specification
| Nom | Min | Max | |
|---|---|---|---|
| Tip Height (h): | 5.25 | 2.5 | 8 |
| Front Angle (FA): | 15 | 12.5 | 17.5 |
| Back Angle (BA): | 25 | 22.5 | 27.5 |
| Side Angle (SA): | 17.5 | 15 | 20 |
